| 产品简介 |
V-SOL V35XX系列是针对运营商IP城域网和企业网络开发的新一代智能交换机。V35XX基于全新高性能硬件和ROS平台，支持ACL、选择性QinQ、1:1和N:1 VLAN切换、以太网OAM、运营商级QoS、工业级10G以太网环等。
| V3528E | V3528EF |
|
24*GE (RJ45) ports
4*10GE/GE (SFP+) ports
|
16*GE (SFP) ports
8*GE (SFP/RJ45 combo) ports
4*10GE/GE (SFP+) ports |
| V3528-P | V3552E |
|
24*GE (RJ45, POE) ports
4*10GE/GE (SFP+) ports
|
48*GE (RJ45) ports
4*10GE/GE (SFP+) ports
|
| Technical parameters |
|
Parameter |
V3528E |
V3528EF |
V3528-P |
V3552E |
|
|
|
|
16*GE (SFP) + |
|
|
|
|
Console(RJ45) |
1 |
1 |
1 |
1 |
|
|
Backplane(Gbps) |
128 |
128 |
128 |
216 |
|
|
Forwarding rate(Mpps with 64 bytes) |
96 |
96 |
96 |
162 |
|
|
Chassis |
Dimensions |
|
|
|
|
|
Weight |
2.4/3.4 |
3.5 |
3.5 |
3.8 |
|
|
|
Dimensions (WxDxH)(mm) |
|
|
|
|
|
Weight(KG) |
3.4/4.4 |
4.5 |
4.5 |
4.6 |
|
|
|
no-load |
＜22W |
＜18W |
＜25W |
＜25W |
|
full-load |
35W |
＜38W |
＜408W |
＜48W |
|
|
|
AC:100V-240V, 50/60Hz DC:-36V~-75V |
|
|
|
|
|
POE power budgest |
/ |
/ |
370W |
/ |
|
|
Total output BTU(1000BTU/H=293W) |
153.58 |
153.58 |
1392.49 |
163.82 |
|
|
Fan number |
/ |
2 |
2 |
2 |
|
|
Noise@25℃(dBA) |
0 |
45 |
37.5 |
45 |
|
|
MTBF(H) |
＞200,000 |
＞200,000 |
＞200,000 |
＞200,000 |
|
|
Forwarding mode |
Store-forward |
Store-forward |
Store-forward |
Store-forward |
|
|
Flash(MB) |
16 |
16 |
16 |
16 |
|
|
DRAM(MB) |
256 |
256 |
256 |
512 |
|
|
MAC |
16K |
16K |
16K |
16K |
|
|
Buffer size(MB) |
1.5 |
1.5 |
1.5 |
1.5 |
|
|
Interface VLAN |
64 |
64 |
64 |
64 |
|
|
Routing table |
512 |
512 |
512 |
512 |
|
|
Jumbo frame |
9K |
9K |
9K |
9K |
|
